Model |
PG1-2000-M-Li |
System Functions |
|
Input Voltage Source ACV-DCV |
|
|
|
Solar Input |
29 ~ 31.5V |
Charging Voltage DCV |
|
Utility Input |
110/240V |
Charging Voltage ACV |
|
Vehicle Input |
Yes |
Charging Voltage DCV |
|
Input Power Source AC-DC |
|
|
|
Solar Power |
350W ~ 480W |
Charging Power |
|
Floating |
<50W |
Floating Charging Power |
|
Utility Power |
201W |
Charging Power |
|
Floating |
<50W |
Floating Charging Power |
|
Vehicle Power |
Yes |
Vehicle Charging Power (DC-DC Converter) |
|
Floating |
<50W |
Floating Charging Power |
|
Utility Charging Duration |
7 ~ 8 Hours |
Charging Duration Hours |
|
Solar Charging Duration |
8 ~ 9 Hours |
Charging Duration Hours |
|
Generator Output Power AC |
|
|
|
Voltage |
110/230V |
Output ACV |
|
Frequency |
50/60Hz±3 |
Output Frequency |
|
Output Amps |
9.0A |
Output Current ACA |
|
Surge Output Current |
18.18A |
Surge Output Current 3sec ACA |
|
THD |
<3% |
Total Harmonic Distortion |
|
Rated Power |
2000W |
Output Power Load |
|
Surge Power |
4000W |
Surge Power Support < 2 Sec |
|
Output Waveform |
Pure Sine Wave |
AC Output Pure Sine Wave |
|
Output Power Socket |
Dual Universal Socket/European |
AC Outlet Power Socket |
|
USB Charger |
Yes |
|
|
Generator Output Power Protection |
|
|
|
OCP |
Yes |
Over Current Protection |
|
OTP |
Yes |
Over temperature protection |
|
OVP |
Yes |
Overvoltage Protection |
|
ACV Short Circuits |
Yes |
Output ACV |
|
Low Voltage Shutdown |
Yes |
AC & DC |
|
Auto Reset |
Yes |
Protected Activated 5sec |
|
Overload Protection |
Yes |
AC-Load |
|
Soft Start |
Yes |
Output: Voltage, Power, Amps |
|
Parallel System |
Yes |
Yes |
|
Efficiency |
>92% |
Output Power Efficiency |
|
Cooling Method |
Yes |
Intelligent Air Cooling |
|
Working Temperature |
20 ° C to 50 °C |
Temperature |
|
Phase |
Single Phase 1ǿ |
Single Phase 2 Wire |
|
Storage Temperature |
-30°- +70° |
Temperature |
|
Humidity |
5% ~ 90% |
Non-Condensing |
|
Reverse Polarity Protection |
Yes |
Dc Input Reverse Polarity |
|
Power Factor |
90 ~ 100 % |
Power Quality |
|
Energy Saving Features |
|
|
|
Online |
Yes |
Charging With Load 24-Hours |
|
Energy Saving Utility |
> 60% @ 500W |
Utility Source |
|
Energy Saving Solar |
100% @ Full Load |
Solar Source |
|
Energy Saving Dual Source |
>70% @ Full Load (U) |
Utility & Solar Dual Source |
|
Physical Size & Weight |
|
|
|
Dimension (mm) |
W250 *L800 *H300 |
Product Dimension |
|
Weight |
26.9kg |
Weight +/- 5% |
 |
